【產品名稱】24聯微波無極UV光解廢氣凈化器

【產品型號】JYM24

【關 鍵 字】紫外線廢氣處理設備,臭氧廢氣處理設備,微波發生器,微波紫外無極燈系統,大流量廢棄處理設備,光氧化,光催化,無極紫外燈,UV光解VOC設備

【產品類別】廢氣處理

【技術原理】微波紫外無極燈成套系統

【產品特點】

1.光解系統多至24套：包括24組可單獨控制電源和6根微波無極紫外燈管；

2.獨立控制光氧系統：24組系統可同時開啟，也可分別控制；

3.開放的前后端接口：接口方便連接PLC系統；

4.強大內部升級空間：可在電控箱內部加配紫外、臭氧等在線監測裝置；

5.全密封并聯管道：紫外輻射集中，臭氧產生量大，氣體處理時間短，處理風量大；

6.體積適宜安全性高：耗能小、占地面積小，自身封裝良好，無微波、紫外泄露。

【應用范圍】

【綜合介紹】

24聯微波無極UV光解廢氣凈化器是基于微波紫外無極燈系統設計的成套氣體處理設備，包括獨立控制的24組電源和24根燈管。24組電源集成在電控箱內，24根電纜從電控箱接出，電纜連接24個激勵器，激勵器焊接在食品級不銹鋼管道上，管道內分別固定24根燈管。集成性高，處理量大，處理時間段，處理效果顯著。該設備已是完整的氣體處理單元，只需要加裝前置的氣體收集裝置、除水、除塵裝置和后續的排放管道，即可構成完整的大風量廢氣處理系統。

【使用說明】

【產品照片】

【視頻資料】

【同系產品】JYM6  JYM4

【規格參數】

[product name] 24 couplet microwave free UV photolysis exhaust purifier
[product model] JYM24
[Key words] ultraviolet exhaust treatment equipment, ozone waste gas treatment equipment, microwave generator, microwave ultraviolet electrodeless lamp system, large flow waste treatment equipment, photo oxidation, photocatalysis, electrodeless ultraviolet lamp, UV photolysis VOC equipment.
Waste gas treatment
A complete system of microwave ultraviolet light free lamp
[product characteristics]
1. photolysis systems are more than 24 sets, including 24 groups of separate control power and 6 microwave non - polar ultraviolet lamps.
2. independent control of the optical oxygen system: the 24 sets of systems can be opened at the same time, and can be controlled separately.
3. open front and back interface: the interface is convenient to connect the PLC system.
4. strong internal upgrade space: can be added with ultraviolet, ozone and other online monitoring devices inside the electronic control box.
5. fully sealed parallel pipeline: the concentration of ultraviolet radiation, the large amount of ozone production, the short treatment time of the gas and the large amount of air handling;
The 6. volume is suitable for high safety: small energy consumption, small area, good encapsulation, no microwave and ultraviolet leakage.
[application range]
[comprehensive introduction]
The 24 microwave endless UV photolysis exhaust gas purifier is a complete set of gas processing equipment based on the microwave ultraviolet electrodeless lamp system, which includes 24 independent power supply and 24 lamp tubes. The 24 power supply is integrated into the electric control box, 24 cables are connected from the electric control box, the cable connects 24 exciter, the actuator is welded on the food grade stainless steel pipeline, and 24 lamps are fixed in the pipeline respectively. High integration, large amount of processing, treatment time, treatment effect is remarkable. The device is already a complete gas processing unit. Only a pre gas collection device, a water removal device, a dust removal device and a subsequent exhaust pipe are needed to form a complete large volume exhaust gas treatment system.
[instructions]
[product photo]
[video data]
[homologous products] JYM6 JYM4
[specification parameter]
